Automatic Deployment Rules – Download Failed – System Center 2012 Configuration Manager

I have just started setting up a new System Center 2012 Configuration Manager server to test in my environment came up against an error that really didn’t make any sense at first.

After running the Automatic Deployment Rule it came up with the Error Code 0x87D20417 further investigation inside the logs in (C:\Program Files\Microsoft Configuration Manager\Logs) found the following entry in the ruleengine.log

Failed to download the update from internet. Error = 5

There was also a status message from SMS_RULE_ENGINE with Severity: Error

Content download failed.
Message: Failed to download one or more content files.
Source: SMS Rule Engine.

When I configured the the new Deployment Package in the “Select deployment package for this automatic deployment rule” section I created a new file share for the package. I set the NTFS permissions as specified in the documentation “Operations and Maintenance for Software Updates in Configuration Manager“.

What I failed to do was allow CHANGE permissions at the share level as I left that at the default READ ONLY setting.

Once I added the CHANGE permission the Automatic Deployment Rule ran and downloaded the software successfully.

Posted in Sys Admin, Systems Center 2012, Windows | Tagged , , , | 2 Comments

Fixed: Location Based Reminders Not Available in iOS 5

If you are having troubles finding location based reminders on your iOS 5 device you are probably using an Exchange based email account. If you have an Exchange account setup on your iPhone or iPad the new reminders app in iOS 5 will be using your Exchange Tasks List. It seems that the Exchange Tasks don’t support the metadata required to have a location based reminder.

To fix this issue you need to add a new Reminder List to your device. This can be easily done by tapping the Edit List button on the main reminders screen (this button has three horizontal lines on it).

Click Edit in the top right corner.

Under the On My iPhone section in the list, tap on Create New List…

Give it a name.

Click Done, and then Done again.

If you swipe sideways you will notice you have a new Reminder List called whatever you named it above. If you now add a reminder in your new list, then go into that reminder and tap “Show More…” you will now have to option to tap on Remind Me, At a Location.

Posted in iPhone | Tagged , , , , , | 2 Comments

Commvault Simpana 9.0 with Granular File Recovery for Linux under VMWare

I am currently going through the process of installing a brand new Commvault installation. One thing I am evaluating is doing most of my backups via the Virtual Server iDataAgent, this will give me “bare metal” recovery of my VM’s as well as cover my individual file restore requirements. As at Simpana 8 granular file level recovery was only supported for NTFS volumes but with the release of Simpana 9 the documentation has been updated to remove the NTFS requirement. Also a nice little line that also says “Granular file-level recoveries are now supported for Linux-based VMware virtual machines.” under the new features in the documentation for Simpana 9.

So testing begins, and you would imagine given the above information that file-level recoveries for Linux would just work. Problem is it just doesn’t work out of the box, after hours of playing with settings and tick boxes and reading forum posts I finally found the solution I needed to get file-level recovery working.

Ok, so to get Linux backup working you need to add a registry entry on the Virtual Server iDataAgent proxy server (the documentation for which can be found here).

HKEY_LOCAL_MACHINE\SOFTWARE\CommVault Systems\Galaxy\Instance001\VirtualServer

Then add the following DWORD value

LinuxMetadataSupport    REG_DWORD    0x00000001

Restart the Commvault agent on the VMWare server for good measure and now take your backup.

As for file system support it seems very limited. I have tested the following setups:

Ubuntu Host
sda1 /boot ext3
sda3 / reiserfs
sda4 /data ext4

Centos Host
LVM2 with partition formatted in ext3

The only file systems that backed up were the EXT3 file systems, LVM appears to be supported as well. One can only assume that EXT2 would be supported, but I haven’t tested this.

Overall this solution can only get better, as more file systems are supported and the option to backup the linux systems on a file level are brought into the GUI it can only get easier from here. Personally I plan on moving forward using the Virtual Server iDataAgent to backup all my VM’s that don’t have special applications on them (ie, database, AD, and Exchange).

Posted in Commvault, Sys Admin, VMWare | Tagged , , , | 3 Comments

FOG: Deleting all current active tasks

FOG is “a free computer cloning solution” found at http://www.fogproject.org/. If your a seasoned user you will no doubt have groups setup so you may run commands on multiple machine without loading each one individually. In my scenario we have 1000 machines that need to be imaged, easy, I just created a group with those particular machines (luckily most computers will have a common part of their MAC address so I could search for machines based on manufacturer). Once the group was created I then setup a task for that group to deploy an image.

OK, whoops, this is when you realise that the machines has the wrong image id assigned to them. Easy you think, you created the task as a group you can just as easily delete the active task as a group. No such luck here, what FOG will do to a group of computers is simply setup an individual task for each and every machine in the group. So your only option now is to click delete on each active task, now multiply this out to 1000 machines you have an annoying problem.

There is a simple solution, although a word of warning here “PLEASE MAKE SURE YOU HAVE A BACKUP”. All the tasks are contained within the “tasks” table within MySQL. So if you feel comfortable crack open a console connection and open up a console to MySQL.

root@fog:/# mysql -u root
Welcome to the MySQL monitor.  Commands end with ; or g.
Server version: 5.0.67-0ubuntu6.1 (Ubuntu)

Type 'help;' or 'h' for help. Type 'c' to clear the buffer.

mysql> use fog;
Reading table information for completion of table and column names
You can turn off this feature to get a quicker startup with -A

Database changed
mysql> delete from tasks where taskState = 0;
Query OK, 8 rows affected (0.23 sec)

mysql>

This will delete all the active tasks running on the fog server. However the command files will still exist in the TFTPROOT folder. Exit out from MySQL and change directory into your TFTPROOT folder. Once inside change into the pxelinux.cfg folder.

You will notice several files in this directory, these are the files that control what a machine will do once it is PXE booted. To delete the command files you ONLY have to delete the files starting with “01-”, this is import as the other files will tell the machines what to do when they don’t have any active tasks.

root@fog:/tftpboot/pxelinux.cfg# rm 01-*

This will have completely removed all the active tasks.

Posted in Linux | Tagged , , | 2 Comments
